Calibration of Vibration Measuring Equipment

A wide range of calibration services for vibration measuring equipment

Accelerometers are used in many important everyday devices that ensure personal safety. In order to perform reliable measurements, your measuring equipment, measuring chains and calibrators must be calibrated at regular intervals.

This way you can ensure that your devices provide reproducible measurements and maintain their required quality level.

  • Accredited calibration services at DAkkS level
  • One-stop-services with SPEKTRA calibration systems
  • Lowest possible measurement uncertainty
  • Reliable contact person and personal advice
  • Short processing time in the laboratory of only 5‑7 working days (optional: express calibration)

Our accreditation certificate

Your vibration transducers and measuring instruments are professionally calibrated by us.

Vibration transducers and vibration measuring instruments

For acceleration and velocity measurement

Secondary calibration in accordance with ISO 16063-21:2003 or DKD-R 3-1 Blatt 3:2018

Primary calibration of reference standards in accordance with ISO 16063-11:1999, ISO 16063-16:2014 or DKD-R 3-1 Blatt 4:2018

  • Frequency range: 1 Hz…20 kHz
  • Acceleration: 0.01 m/s²…250 m/s²



Vibration calibrators and calibration systems can be calibrated by us worldwide.

Vibration calibrators and calibration systems

Calibration in accordance with ISO 16063-11:1999, ISO 16063-21:2003, DKD-R 3-1 Blatt 3:2018, DKD-R 3-1 Blatt 4:2018

Primary calibration of integrated vibration transducers in vibration exciters (internal standards) in accordance with ISO 16063-11

  • Frequency range: 1 Hz…20 kHz
  • Acceleration: 0.01 m/s² and 250 m/s²



SPEKTRA offers a calibration service for triaxial acceleration sensors.

Inertial Measurement Units (IMU)

Calibration of acceleration and angular rate in three axes.

Learn more



Inertial Navigation System (INS)

DAkkS and factory calibration of devices with INS receivers for the measurand velocity.

  • triaxial rotation velocity at DAkkS level
  • only manufacturer-independent calibration laboratory in Europe
  • short throughput times = low downtimes



Details GNSS/INS calibration



We also have the right service for special vibration measurement technology such as geophones.

Further services for vibration measuring equipment

Vibration and shock tests are used in various areas – from modal analysis to fatigue tests and quality inspection of prototypes. In addition to the calibration of vibration measuring equipment, we offer further services for shock as measurand.

Geophones and seismometers are also important devices using vibration measurement technology. Did you know? We can calibrate these devices for you!

Matching service for your device: Use our service finder now!

?
?
?

References

Reference_014
Reference_013
Reference_040
Reference_020
Reference_023

Six simple steps to your certificate

6 simple steps of SPEKTRAs service process

Key Features

Frequency Range

  • 0.1 Hz…20 kHz (DAkkS-accredited)

Acceleration

  • 0.01 m/s²…250 m/s²

Calibration in accordance with

  • ISO 16063-11
  • ISO 16063-21
Mascot_Question



Why is calibration
even required?

Here you will find an interesting overview with definitions,
further information and more about the benefits of our calibration services.

«Which service fits your device? Contact us!
We will find the right solution for you.»

SPEKTRA Sales Team

+49 351 400 24 0

Alternative systems

You would like to carry out the calibration by yourself? SPEKTRA offers you suitable system components.
